| Led Arrangement | GOB |
| Module Dimensions | 320x160dots |
| Module Resolution | 256x128dots | 208x104dots | 172x86dots | 160x80dots | 128x64dots |
| Module scan | 1/64s | 1/52s | 1/43s | 1/40s | 1/32s |
| Display size | 320x480mm/320x640mm/320x960mm (WxH) |
| Outersize | 380x1125mm / 380x1195mm/380x1285mm / 380x1335mm with acrylic box |
| Material | Iron |
| Cabinet Weight | 25kg/28kg/32kg per screen |
| Brightness | >600nits |
| Max Power Consumption | 440w/m² |
| Ave Power Consumption | 145w/m² |
| Viewing Angle | 160°(W)/160°(H) |
| Operating Power source | 110-240VAC50 – 60Hz |
| Operating Temperature | -20°C – +50°C |
| Refresh Rate | 3840Hz |
| IP Rating | IP43 |
| Video Interface | HDMI2(1 input and 1 output), USB 2.01 |
| Audio Interface | RJ45, WIFI, AP Local Network, 4G Network(Optional) |
| Control interface | Composite, S Video, Component, HDMI, ISDI, HD, VGA, DV |
| Installation/Maintenance | Standing (Stacking, Hanging, Wall Mounting (Optional)) |
| Certificate | MET, ETL, FCC, CE, RoHS |
